The vibrator, centering device and box adopt split modular design, which makes maintenance simple and replacement more convenient, minimizing downtime;
The vibration support device adopts a rotating shaft type, and the vibrating screen can be freely adjusted by 10-20 degrees to meet the different material screening needs of customers;
Adding a transmission device improves the motor transmission efficiency and extends the service life of the V-belt; ensures the concentricity of the equipment operation and greatly extends the service life of the bearing;
It effectively controls the lateral swing amplitude of the equipment and increases the service life of the machine body and composite spring.
model | Screen layers | Screen size (mm) | Maximum feed size (mm) | Processing capacity (t/h) | Double amplitude(mm) | Motor power (kw) | Screen surface specifications (mm) |
2ZY1237 | 2 | 3-50 | 200 | 10-100 | 7-10 | 11 | 1200×3600 |
3ZY1237 | 3 | 3-50 | 200 | 10-100 | 7-10 | 11 | 1200×3600 |
2ZY1548 | 2 | 3-80 | 300 | 22-165 | 7-10 | 15 | 1500×4800 |
3ZY1548 | 3 | 3-80 | 300 | 22-165 | 7-10 | 15 | 1500×4800 |
2ZY1848 | 2 | 3-80 | 300 | 35-275 | 7-10 | 18.5 | 1800×4800 |
3ZY1848 | 3 | 3-80 | 300 | 35-275 | 7-10 | 18.5 | 1800×4800 |
2ZY1860 | 2 | 3-80 | 300 | 65-590 | 7-10 | 22 | 1800×6000 |
3ZY1860 | 3 | 3-80 | 300 | 65-590 | 7-10 | 22 | 1800×6000 |
4ZY1860 | 4 | 3-80 | 300 | 65-590 | 7-10 | 30 | 1800×6000 |
2ZY2070 | 2 | 3-100 | 300 | 95-700 | 7-10 | 30 | 2000×7000 |
3ZY2070 | 3 | 3-100 | 300 | 95-700 | 7-10 | 30 | 2000×7000 |
4ZY2070 | 4 | 3-100 | 300 | 95-700 | 7-10 | 37 | 2000×7000 |
2ZY2160 | 2 | 3-100 | 300 | 85-750 | 7-10 | 30 | 2100×6000 |
3ZY2160 | 3 | 3-100 | 300 | 85-750 | 7-10 | 30 | 2100×6000 |
4ZY2160 | 4 | 3-100 | 300 | 85-750 | 7-10 | 37 | 2100×6000 |
2ZY2460 | 2 | 3-120 | 300 | 90-850 | 6-9 | 37 | 2400×6000 |
3ZY2460 | 3 | 3-120 | 300 | 90-850 | 6-9 | 37 | 2400×6000 |
4ZY2460 | 4 | 3-120 | 300 | 90-850 | 6-9 | 45 | 2400×6000 |
2ZY2860 | 2 | 3-120 | 300 | 110-1000 | 6-9 | 45 | 2800×6000 |
3ZY2860 | 3 | 3-120 | 300 | 110-1000 | 6-9 | 45 | 2800×6000 |
2ZY3073 | 2 | 3-120 | 300 | 150-1300 | 6-9 | 30×2 | 3000×7300 |
3ZY3073 | 3 | 3-120 | 300 | 150-1300 | 6-9 | 30×2 | 3000×7300 |
2ZY3673 | 2 | 3-120 | 300 | 180-1600 | 6-9 | 30×2 | 3600×7300 |
3ZY3673 | 3 | 3-120 | 300 | 180-1600 | 6-9 | 37×2 | 3600×7300 |
